AR1:
<Huawei>UN T M Info: Current terminal monitor is off. <Huawei>sys Enter system view, return user view with Ctrl+Z. [Huawei]sysn AR1 [AR1]user-i [AR1]user-interface con 0 [AR1-ui-console0]idle-timeout 0 0 [AR1-ui-console0]qu [AR1]int g0/0/0 [AR1-GigabitEthernet0/0/0]ip add 10.1.0.1 16 [AR1-GigabitEthernet0/0/0]un shut Info: Interface GigabitEthernet0/0/0 is not shutdown. [AR1-GigabitEthernet0/0/0]int loop 0 [AR1-LoopBack0]ip add 1.1.1.1 32 [AR1-LoopBack0]qu [AR1]ospf 1 router-id 1.1.1.1 [AR1-ospf-1]area 3 [AR1-ospf-1-area-0.0.0.3]network 1.1.1.1 0.0.0.0 [AR1-ospf-1-area-0.0.0.3]net [AR1-ospf-1-area-0.0.0.3]network 10.1.0.0 0.0.255.255 [AR1-ospf-1-area-0.0.0.3]stub [AR1-ospf-1-area-0.0.0.3]q [AR1-ospf-1]q [AR1]disp ospf peer OSPF Process 1 with Router ID 1.1.1.1 Neighbors Area 0.0.0.1 interface 12.1.1.1(GigabitEthernet0/0/0)'s neighbors Router ID: 2.2.2.2 Address: 12.1.1.2 State: Full Mode:Nbr is Master Priority: 1 DR: 12.1.1.1 BDR: 12.1.1.2 MTU: 0 Dead timer due in 29 sec Retrans timer interval: 5 Neighbor is up for 00:12:21 Authentication Sequence: [ 0 ] [AR1]ping -a 1.1.1.1 6.6.6.6 PING 6.6.6.6: 56 data bytes, press CTRL_C to break Reply from 6.6.6.6: bytes=56 Sequence=1 ttl=251 time=80 ms Reply from 6.6.6.6: bytes=56 Sequence=2 ttl=251 time=50 ms Reply from 6.6.6.6: bytes=56 Sequence=3 ttl=251 time=60 ms Reply from 6.6.6.6: bytes=56 Sequence=4 ttl=251 time=40 ms Reply from 6.6.6.6: bytes=56 Sequence=5 ttl=251 time=50 ms --- 6.6.6.6 ping statistics --- 5 packet(s) transmitted 5 packet(s) received 0.00% packet loss round-trip min/avg/max = 40/56/80 ms [AR1]disp ip routing-table Route Flags: R - relay, D - download to fib ------------------------------------------------------------------------------ Routing Tables: Public Destinations : 9 Routes : 9 Destination/Mask Proto Pre Cost Flags NextHop Interface 0.0.0.0/0 OSPF 10 2 D 10.1.0.2 GigabitEthernet 0/0/0 1.1.1.1/32 Direct 0 0 D 127.0.0.1 LoopBack0 10.1.0.0/16 Direct 0 0 D 10.1.0.1 GigabitEthernet 0/0/0 10.1.0.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/0 10.1.255.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/0 127.0.0.0/8 Direct 0 0 D 127.0.0.1 InLoopBack0 127.0.0.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0 127.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0 255.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0 [AR1] <Huawei>UN T M Info: Current terminal monitor
