R4:
<Huawei>un t m Info: Current terminal monitor is off. <Huawei>sys Enter system view, return user view with Ctrl+Z. [Huawei]user-interface con 0 [Huawei-ui-console0]idle-timeout 0 0 [Huawei-ui-console0]qu [Huawei]int g0/0/0 [Huawei-GigabitEthernet0/0/0]ip address 10.1.1.1 24 [Huawei-GigabitEthernet0/0/0]q [Huawei]int LoopBack 0 [Huawei-LoopBack0]ip address 1.1.1.1 32 [Huawei-LoopBack0]q [Huawei]int g0/0/0 [Huawei-GigabitEthernet0/0/0]un shut Info: Interface GigabitEthernet0/0/0 is not shutdown. [Huawei-GigabitEthernet0/0/0]qu [Huawei]ip route-static 0.0.0.0 0.0.0.0 10.1.1.2 [Huawei]int e0/0/0 [Huawei-Ethernet0/0/0]ip address 10.1.3.1 24 [Huawei-Ethernet0/0/0]un shut Info: Interface Ethernet0/0/0 is not shutdown. [Huawei-Ethernet0/0/0]qu [Huawei]ip route-static 0.0.0.0 0.0.0.0 10.1.3.2 preference 61 [Huawei]int g0/0/0 [Huawei-GigabitEthernet0/0/0]shut [Huawei-GigabitEthernet0/0/0]qu [Huawei]disp ip routing-table Route Flags: R - relay, D - download to fib ------------------------------------------------------------------------------ Routing Tables: Public Destinations : 8 Routes : 8 Destination/Mask Proto Pre Cost Flags NextHop Interface 0.0.0.0/0 Static 60 0 RD 10.1.1.2 GigabitEthernet 0/0/0 1.1.1.1/32 Direct 0 0 D 127.0.0.1 LoopBack0 10.1.1.0/24 Direct 0 0 D 10.1.1.1 GigabitEthernet 0/0/0 10.1.1.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/0 10.1.3.0/24 Direct 0 0 D 10.1.3.1 Ethernet0/0/0 10.1.3.1/32 Direct 0 0 D 127.0.0.1 Ethernet0/0/0 127.0.0.0/8 Direct 0 0 D 127.0.0.1 InLoopBack0 127.0.0.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0 [Huawei]int g0/0/0 [Huawei-GigabitEthernet0/0/0]shutdown [Huawei-GigabitEthernet0/0/0]qu [Huawei]disp ip routing-table Route Flags: R - relay, D - download to fib ------------------------------------------------------------------------------ Routing Tables: Public Destinations : 6 Routes : 6 Destination/Mask Proto Pre Cost Flags NextHop Interface 0.0.0.0/0 Static 61 0 RD 10.1.3.2 Ethernet0/0/0 1.1.1.1/32 Direct 0 0 D 127.0.0.1 LoopBack0 10.1.3.0/24 Direct 0 0 D 10.1.3.1 Ethernet0/0/0 10.1.3.1/32 Direct 0 0 D 127.0.0.1 Ethernet0/0/0 127.0.0.0/8 Direct 0 0 D 127.0.0.1 InLoopBack0 127.0.0.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0 [Huawei] [Huawei]ping -a 1.1.1.1 3.3.3.3 PING 3.3.3.3: 56 data bytes, press CTRL_C to break Reply from 3.3.3.3: bytes=56 Sequence=1 ttl=254 time=100 ms Reply from 3.3.3.3: bytes=56 Sequence=2 ttl=254 time=60 ms Reply from 3.3.3.3: bytes=56 Sequence=3 ttl=254 time=60 ms Reply from 3.3.3.3: bytes=56 Sequence=4 ttl=254 time=80 ms Reply from 3.3.3.3: bytes=56 Sequence=5 ttl=254 time=60 ms --- 3.3.3.3 ping statistics --- 5 packet(s) transmitted 5 packet(s) received 0.00% packet loss round-trip min/avg/max = 60/72/100 ms [Huawei] <Huawei>un t m Info: Current terminal monitor
