SW1：
<Huawei>undo terminal monitor <Huawei>system-view [Huawei]user-interface console 0 [Huawei-ui-console0]idle-timeout 0 0 [Huawei-ui-console0]sysname SW1 [SW1]int g0/0/1 [SW1]vlan batch 10 20 30 40 [SW1]int g0/0/1 [SW1-GigabitEthernet0/0/1]port link-type access [SW1-GigabitEthernet0/0/1]port default vlan 10 [SW1-GigabitEthernet0/0/1]int g0/0/2 [SW1-GigabitEthernet0/0/2]port link-type access [SW1-GigabitEthernet0/0/2]port default vlan 20 [SW1-GigabitEthernet0/0/2]int g0/0/3 [SW1-GigabitEthernet0/0/3]port link-type access [SW1-GigabitEthernet0/0/3]port default vlan 30 [SW1-GigabitEthernet0/0/3]int g0/0/4 [SW1-GigabitEthernet0/0/4]port link-type access [SW1-GigabitEthernet0/0/4]port default vlan 20 [SW1-GigabitEthernet0/0/4]int g0/0/6 [SW1-GigabitEthernet0/0/6]port link-type access [SW1-GigabitEthernet0/0/6]port default vlan 10 [SW1-GigabitEthernet0/0/6]int g0/0/5 [SW1-GigabitEthernet0/0/5]port link-type access [SW1-GigabitEthernet0/0/5]port default vlan 40 [SW1-GigabitEthernet0/0/5]quit [SW1]int vlanif 10 [SW1-Vlanif10]ip add 192.168.10.1 24 [SW1-Vlanif10]undo shutdown [SW1-Vlanif10]int vlanif 20 [SW1-Vlanif20]ip add 192.168.20.1 24 [SW1-Vlanif20]undo shutdown [SW1-Vlanif20]int vlanif 30 [SW1-Vlanif30]ip add 192.168.30.1 24 [SW1-Vlanif30]undo shutdown [SW1-Vlanif30]int vlanif 40 [SW1-Vlanif40]ip add 11.0.0.2 24 [SW1-Vlanif40]undo shutdown [SW1-Vlanif40]quit [SW1]ip route-static 0.0.0.0 0.0.0.0 11.0.0.1 <Huawei>undo terminal monitor <Huawei>system-
